FPC COMP D8100

$216.40$2,814.24

Clear

Description

The FPC COMP D Series are synthetic compressor oils specially formulated with premium synthetic ester base fluids for use in a wide variety of air compressors. FPC COMP D8100 is designed from diester base oils for reciprocating compressors and is recommended for high pressure air compressors.

FPC COMP D8100 is recommended for reciprocating compressors and vacuum pumps using the following gases:

Air
Ethylene
Methane
Propane
Butadiene
Natural gas
Synthesis gas
Carbon monoxide
Carbon dioxide (dry)
Helium
Hydrogen sulfide (dry)
Nitrogen
Furnace (crack) gas
Hydrogen
Sulphur Hexafluoride

Nominal operating Range is -15°C to 230°C (5°F to 445°F).

Cross-Reference

This lubricant is equivalent to the following products.

CompanyProduct
ChampionChampLube Synthetic
CompAirCs-300
CurtisRc-1500
Gardner DenverAeon AC-SY
Ingersoll RandAll Season Select
Ingersoll RandT-30 Select
Ingersoll RandXL-700
KaeserSigma S-100

Technical Information

TYPICAL PROPERTIESTEST METHODFPC COMP D8100
ISO GradeASTM D2422100
SAE GradeSAE J-30030
Viscosity @ 40°C, cStASTM D44599
Viscosity @ 100°C, cStASTM D44510.2
Viscosity IndexASTM D227083
Flash Point, °C/°FASTM D92260/500
Pour Point, °C/°FASTM D97-33/-27
Copper CorrosionASTM D1301a
Foaming Sequences I, II, IIIASTM D892< 10/0
DemulsibilityASTM D1401Excellent
Evaporation, %ASTM D9721.0
Carbon Residue, %ASTM D189< 0.01
Specific GravityASTM D12980.95

Data Sheet Case Study

FPC Lubricants are proudly manufactured in the USA, under the strictest ISO 9001:2015 quality management standards.



Typical Industrial Applications

  • Reciprocating compressors
  • High pressure
  • Air compressors
  • Vacuum pumps

Performance Benefits

  • Outstanding thermal and oxidative stability
  • Will not varnish or form carbon deposits
  • Wide operating temperature range
  • Built-in detergency action
  • Extended drain intervals reduces oil disposal, thus increasing cost effectiveness
  • USDA H-2 authorized
  • Caution: May affect some paint finishes, plastics and seals
