Description

The FPC COMP M Series is a group of high performance, multifunctional lubricants designed for use in many industrial applications. These are considered environmentally friendly since they are zinc free. These premium petroleum oils are the answer where OEM specifications are critical. They are very useful where frequent change-outs are necessary due to poor environments prone to contamination from dust, acids, solvents, gases, or other contaminants. FPC COMP M2068 has a service life up to 2,000 hours in reciprocating compressors. The additive chemistry found in this series provides high performance ashless hydraulic fluids and compressor oils with antiwear properties.

Cross-Reference

This lubricant is equivalent to the following products.

Company	Product
Curtis	Rc-1000
Gardner Denver	Aeon 500
Quincy	Quincip 68

Technical Information

TYPICAL PROPERTIES	TEST METHOD	FPC COMP M2068
ISO Grade	ASTM D2422	68
Viscosity @ 40°C, cSt	ASTM D445	69
Viscosity @ 100°C, cSt	ASTM D445	9.3
Viscosity Index	ASTM D2270	112
Flash Point, °C/°F	ASTM D92	217/424
Pour Point, °C/°F	ASTM D97	-34/-29
Copper Corrosion	ASTM D130	1b
Rust – Sea Water	ASTM D665B	Pass
Specific Gravity	ASTM D4052	0.87

Data Sheet Case Study

FPC Lubricants are proudly manufactured in the USA, under the strictest ISO 9001:2015 quality management standards.

Typical Industrial Applications

• Rotary screw compressors
• Reciprocating compressors
• High pressure hydraulic systems

Performance Benefits

• Excellent rust and oxidation inhibitors
• Zinc free
• Will not foam
• Great demulsibility

The FPC COMP M Series oils are suitable for antiwear hydraulic fluids according to:

• Cincinnati Machine P-68, P-69, P-70
• Denison HF-0, HF-1, HF-2
• DIN 51524, Part 2 and 3 (HLP, HVLP)
• ISO 6743/4 (HM, HV)
• ISO 11158 (HM, HV)
• AFNOR NF E 48-603 (HM, HV), SS 155434
• SEB 181 222
• U.S. Steel 126, 127 and 136

The FPC COMP M Series oils are suitable for compressor oils according to:

• DIN 51506 (VBL, VCL, VDL)
• ISO / DP 6521 (DAA, DAB, DAH, DAG)
